OPTICAL MEASUREMENT SYSTEM SOLUTION
SOPHISTICATED NFP MEASUREMENT SYSTEM FOR HIGH POWER LASER
PRODUCT OVERVIEW
SOPHISTICATED NFP MEASUREMENT SYSTEM FOR HIGH POWER LASER
Sophisticated NFP Measurement System For High Power Laser is a high performance beam profiler system for measuring and analyzing the optical beam profile of output ~10 W class high power laser.
As the measurement optics, Synos' Sophisticated NFP Measurement Optics For High Power Laser M-Scope type HS is used. A two-stage beam sampler unit (light reduction unit) is installed after the objective lens. This allows you to select and change the objective lens magnification. Additionally, it is possible to measure beam divergence of collimated beam (measurement with no objective lens attached).
This system is ideal for high performance laser beam profiler for output ~10W class high power laser in 400~1100nm spectral range.
In combination with M-Scope type HS, detector and Optical Beam Analysis Module AP013, it will be possible to easily build NFP and optical beam profile measurement system for various high power laser devices.
FEATURE
- Synos’ Sophisticated NFP Measurement Optics For High Power Laser M-Scope type HS
- Optics selection
- for 400~450nm : M-Scope type HS/BL
- for 850~940nm : M-Scope type HS/NIR
- *Please contact us for the measurement wavelength
- A two-stage beam sampler unit (light reduction unit) is installed after the objective lens.
- It is possible to select object lens magnification
- Coaxial epi-illumination for image observation can be installed (option).
- Detector selection
- for 400~1100nm : High Resolution CMOS Detector ISA071/ISA071GL
- Synos' Optical Beam Analysis Module AP013, image processing, data aquisition and analysis system for optical beam analysis.
- All-in-one package system with PC for data processing, Optical Beam Analysis Software Optometrics BA Standard, sensor driver software, calibration data set for data analysis. Possible to start up measurement system quickly after system introduction.
- Optometrics BA Standard, specially designed high-functional image processing software for optical beam profile analysis
- Essential and useful functionality for NFP, FFP, beam profile analysis are equipped in Optometrics BA Standard.
- EF/EAF analysis function is installed as standard function.
APPLICATION
- Laser beam profiler, NFP (optical beam profile) measurement of output ~10W class high power laser and related optical module
- Beam profile measurement of high power laser for biometric authentication, automotive application, illumination, laser machining, medical, solid laser excitation, printing, etc.
- Beam profile measurement of various high power lasers in general
SYSTEM COMPONENT SELECTION
SYSTEM CONFIGURATION DIAGRAM
COMPONENT SELECTION
- Optics selection
- Sophisticated NFP Measurement Optics For High Power Laser M-Scope type HS
- for 400~450nm : M-Scope type HS/BL
- for 850~940nm : M-Scope type HS/NIR
- Please contact us for other measurement wavelengths.
- Detector
- 400~1100nm：High Resolution CMOS Detector ISA071/ISA071GL
- Optical Beam Analysis Module AP013
- Personal Computer for data processing
- Optical beam analysis software Optometrics BA Standard
- Calibration data set for NFP measurement
- Driver software for imaging detector
- Accessories
- Cables
- Documents (instruction manuals, etc.)
OPTIONAL UNITS・ACCESSORIES SELECTION
- Option for M-Scope type HS
- Dummy Filter Set MS-OP016-DF
- Wedge type dummy filter set for measurement of low power/pulse emission sample
- 2× Intermediate Lens Port MS-OP011-RL2
- Intermediate lens unit that doubles the overall magnification of the optical system. (up to 200× with 100× objective lens）
- 1/2× Intermediate Lens Port MS-OP011-RLH
- Intermediate lens unit that halves the overall magnification of the optical system.
- Coaxial Epi-illumination Port MS-OP011-CEP
- Coaxial epi-illumination port with removable half mirror.
- About optional units for M-Scope type HS in details, please refer to here.
- ND filter (designated 30mmφ)
- for 400~450nm : NDF VIS30-5 (10%, 5%, 1%, 0.1%, 0.01%)
- for 850nm~940nm ：NDF NIR30-5 (10%, 5%, 1%, 0.1%, 0.01%)
- Coaxial epi-illumination system
- About coaxial epi-illumination system, refer to here.
- Optics base and workbench
- Optics bench for optical fiber measurement
- Vertical type optics bench
- About optics base and workbench, please refer to here.
