COLLIMATED BEAM MEASUREMENT SYSTEM

PRODUCT OVERVIEW
COLLIMATED BEAM MEASUREMENT SYSTEM

mscopetypes

Collimated Beam Measurement System is for observation and analysis system of collimated beam condition, best for collimator lens alignment of various collimator devices and modules. Synos’ M-Scope type C, Collimated Beam Measurement Optics, is adopted in this system.

In combination with M-Scope type C, imaging detector and Synos' Optical Beam Analysis Module AP013, it realizes quick and realtime observation and measurement of collimated beam condition of various optical devices and modules.

By selecting imaging detector, it will be applicable for optical beam profile observation and analysis in 400nm~1700nm spectral range, corresponding to measurement wavelength and purpose.

It realizes the collimator lens position alignment and adjustment easily and quickly by realtime observation and analysis of collimated beam. In addition, in combination with motorized automatic positioning stage system and image processing, it is also applicable for automatic alignment and adjustment system of various collimator modules.

FEATURE

  • Synos’ M-Scope type C, Collimated Beam Measurement Optics, is adopted as measurement optics
    • High resolution and realtime observation and analysis of collimated beam condition emitted from various collimator module.
  • Possible to select suitable imaging detector in 400~1700nm spectral range
    • for 400~1100nm : High Resolution CMOS Detector ISA071/ISA071GL
    • for 950nm~1700nm : InGaAs High Sensitivity NIR Detector ISA041H2
    • 【NEW】for 400nm~1700nm : SXGA InGaAs High Resolution NIR Detector ISA041HRA
  • Synos' Optical Beam Analysis Module AP013, image processing, data aquisition and analysis system for optical beam analysis.
    • All-in-one package system with PC for data processing, Optical Beam Analysis Software Optometrics BA Standard, sensor driver software, calibration data set for data analysis. Possible to start up measurement system quickly after system introduction.
    • Optometrics BA Standard, specially designed high-functional image processing software for optical beam profile analysis
      • Essential and useful functionality for NFP, FFP, beam profile analysis are equipped in Optometrics BA Standard.
      • EF/EAF analysis function is installed as standard function.
  • High system expandability with various optional units
    • In combination with various positioning stages, it is possible to build up manual or automatic assembling adjustment system for collimator module, butterfly package module and so on.

APPLICATION

  • Evaluation of collimated beam quality
  • Collimator lens adjustment of various VIS-NIR LD modules.
  • Alignment, adjustment, evaluation of various collimator modules
  • Alignment, adjustment, evaluation of collimator lens installed in butterfly package LD modules

SYSTEM COMPONENT SELECTION

SYSTEM CONFIGURATION DIAGRAM
COMPONENT SELECTION
  • Collimated Beam Measurement Optics M-Scope type C selection
    • M-Scope type C/200 : focal length 200mm type
    • M-Scope type C/150 : focal length 150mm type
    • M-Scope type C/100 : focal length 100mm type
    • About M-Scope type C selection, please refer to here.
  • Detector selection
    • 400~1100nm: High Resolution CMOS Detector ISA071/ISA071GL
    • 950~1700nm: InGaAs High Sensitivity NIR Detector ISA041H2
    • 400~1700nm: 【NEW】InGaAs High Resolution NIR Detector ISA041HRA
      • About optical sensor selection, please refer to here.
  • Optical Beam Analysis Module AP013
    • Personal Computer for data processing
    • Optical beam analysis software Optometrics BA Standard
    • Calibration data set for NFP measurement
    • Driver software for imaging detector
  • Accessories
    • Cables
    • Documents (instruction manuals, etc.)
OPTIONAL UNITS・ACCESSORIES SELECTION
  • Objective lens
    • By using objective lens, it is possible to observe NFP image
    • About objective lens selection, please refer to here.
  • ND filter
    • for visible(400~700nm):NDF-5
    • for NIR(700nm~1100nm):NDF NIR-5
    • for IR(1310nm~1550nm):NDF IR-5
      • About ND filter, please refer to here.
  • Optics base and workbench
    • Optics bench for optical fiber measurement
    • Vertical type optics bench
      • About optics base and workbench, please refer to here.
  • System customization
    • Depend on requirement, it is possible to build up automatic/semi-automatic/manual collimator assembling adjustment system.

RELATED PRODUCT INFORMATION

  • Optical Beam NFP Measurement System
    • High functional NFP/beam profile measurement system by dedicated optics and image processing method.
  • FFP Measurement System
    • FFP measurement system by dedicated optics and image processing method
  • Optical Beam Analysis Module AP013
    • All-in-one package high functional optical beam profile analysis system with PC for data processing, Optical Beam Analysis Software Optometrics BA Standard, detector driver software, calibration data set for data analysis. Possible to start up measurement system quickly after system introduction.
  • In addition, we have a variety of optical measurement units and systems for various purposes and applications.
